Transfer Dies

Transfer dies are ideal for forming complex parts that require multiple operations that are not possible in a single-station or progressive setup. Our in-house engineers design and build transfer die systems that combine precision, reliability, and seamless integration with your automation process.

Our transfer dies are engineered for use with mechanical, hydraulic, or servo-driven transfer systems. Each station in the die is designed to perform critical operations such as forming, piercing, trimming, or flanging—while maintaining part alignment and structural integrity. We build transfer dies with robust nests, precision guides, and hardened tooling for long-lasting durability. Whether used for deep-drawn parts, irregular geometries, or heavy-gauge materials, our transfer tooling is built to perform flawlessly from trial run to full-scale production.

• Ideal for large or complex parts with multiple forming stages
• Works with robotic or mechanical transfer press lines
• Heavy-duty construction for high-tonnage applications
• Hardened die sections and tight tolerance locating features
• Smooth part handoff between stations for consistent geometry
• Custom risers, lifters, and guides engineered to your system
• On-site tryout support and integration assistance available
• Used in automotive housing, underbody components, trays, and more
